Product Carousel Tabs
1/4W Kilo ohms Values, 1/4W Mega ohms Values, 1/4W Ohms Values, All Products, Capacitors, General Purpose BJT Transistors, LED's & LASER Sources
Electronic Components Starter Package
All Products, Clamp Meter | Power Meter, UNI-T Brand Products
Clamp Meter UT210E True RMS (NEW Model)
All Products, Clamp Meter | Power Meter, UNI-T Brand Products
Clamp Meter UT210E True RMS (NEW Model)
| Specifications | Range | UT210E |
| AC current (A) | 100A | ±(2.5%+5) |
| DC current (A) | 100A | ±(2%+3) |
| AC voltage (V) | 600V | ±(1%+3) |
| DC voltage (V) | 600V | ±(0.7%+3) |
| Resistance (Ω) | 20MΩ | ±(1%+2) |
| Capacitance (F) | 20mF | ±(4%+5) |
| Features | ||
| Display count | 2000 | |
| Continuity buzzer | √ | |
| Auto range | √ | |
| Jaw opening | 17mm | |
| Diode test | Around 3.0V | √ |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 2 | |
| Display | 39.3mm x 26.5mm | |
| Product color | Red and grey | |
| Product net weight | 170g | |
| Product size | 175mm x 60mm x 33.5mm | |
| Standard accessories | Batteries, test leads | |
SKU: AVO.UT210E.UNIT
All Products, Clamp Meter | Power Meter, Power Inverter
UT230B-EU Power Socket (Power Consumption Meter)
All Products, Clamp Meter | Power Meter, Power Inverter
UT230B-EU Power Socket (Power Consumption Meter)
| Specifications | Range | UT230B-EU |
| Voltage | 100V~260V | ±1% |
| Current | 0A~16A | ±1% |
| Power | 1~3680W | ±1% |
| Power factor | 0~1 | ±2% |
| Energy consumption | 0~9999kWh | ±1% |
| Features | ||
| Unit price of electricity | 0~99.99 ($/kWh) | √ |
| Accumulative time | 0 minute~9999 days | √ |
| Accumulative charge | 0~9999$ | √ |
| CO2 display | 0~9999kg | √ |
| Power consumption | <0.4W | √ |
| Overload indication | >16A | |
| General Characterisitics | ||
| Power | 3V button battery | |
| Display | 48mm x 30.5mm | |
| Product color | White | |
| Product net weight | 155g | |
| Product size | 130mm x 65mm x 37mm | |
| Standard accessories | Battery | |
SKU: AVO.UT230B.UNIT
All Products, Distance Meter, Environmental Meters & Testers, UNI-T Brand Products
LM40 Laser Distance Meter (up to 40 meter)
All Products, Distance Meter, Environmental Meters & Testers, UNI-T Brand Products
LM40 Laser Distance Meter (up to 40 meter)
| Specifications | LM40 |
| Display type | EBTN |
| Display size | 2.0-inches |
| Range | 40m |
| Min. display unit | 0.001m |
| Measurement units | m/ft/in |
| Measurement basis | front/rear |
| Accuracy | ±(2mm+5 x 10-5D) |
| Laser class | 2 |
| Laser type | 630~670nm, ﹤1mW |
| Features | |
| Single measurement | √ |
| Continuous measurement | √ |
| Max/Min/Area | √ |
| Volume | √ |
| Pythagoras | √ |
| Add/Subtract | √ |
| Data storage | 20 groups |
| Auto power off | 3 minutes without operation |
| Auto laser off | 30s without operation |
| Auto backlight off | 10s without operation |
| Audio indication | √ |
| Battery status display | √ |
| Storage temperature | -20℃~70℃ |
| Operating temperature | 0℃~40℃ |
SKU: AVO.LM40.UNIT
All Products, Digital Multimeter, UNI-T Brand Products
UT89X Digital Multimeter (NEW Featured Model)
| Specifications | Range | UT89X |
| DC voltage (V) | 600mV/6V/60V/600V/1000V | ±(0.5%+2) |
| AC voltage (V) | 6V/60V/600V/1000V | ±(0.8%+5) |
| DC current (A) | 60μA/60mA/600mA/20A | ±(0.8%+8) |
| AC current (A) | 60mA/600mA/20A | ±(1%+12) |
| Resistance (Ω) | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | ±(0.8%+3) |
| Capacitance (F) | 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF/100mF | ±(2.5%+20) |
| Frequency (Hz) | 9.999Hz/9.999MHz | ±(0.1%+4) |
| Duty cycle | 0.1%~99.9% | ±(2%+5) |
| Temperature (℃) | -40℃~1000℃ | ±(2%+4) |
| Temperature (℉) | -40℉~1832℉ | ±(2%+8) |
| Features | ||
| Display count | 6000 | |
| Sampling rate | 3 times/s | |
| True RMS | √ | |
| AC voltage frequency response | 45~1000Hz | |
| AC current frequency response | 45~1000Hz | |
| Live wire test | √ | |
| Audible/visual alarm | V/A/Cap/Diode/hFE/NCV/Live (UT89X)/LED (UT89XD) | |
| Diode/Continuity test | √ | |
| Transistor hFE | √ | |
| Dual range NCV test | √ | |
| Auto power off | √ | |
| Low battery indication | √ | |
| Data hold | √ | |
| Function selection | SELECT | √ |
| Flashlight | √ | |
| Auto backlight | √ | |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 4 | |
| Display | 61mm x 36mm | |
| Product color | Red and grey | |
| Product net weight | 345g | |
| Product size | 189mm x 89mm x 53mm | |
| Standard accessories | Batteries, test lead, k-type temperature probe | |
SKU: AVO.UT89X.UNIT
All Products, Microcontrollers Kits, RAM Training Board
Atmel AVR USB Development System Eta32mini Ver.2
All Products, Microcontrollers Kits, RAM Training Board
Atmel AVR USB Development System Eta32mini Ver.2
GENERAL DESCRIPTION
Eta32mini kit is an AVR development board designed particularly for students, beginners and recent graduated ngineers to provide easy developing of AVR microcontroller projects. Eta32mini supports ATMEGA32 microcontroller chip. Eta32mini kit provides the most common primary devices and circuits, such as LCD, KEYPAD, serial interface, and more. Thus, it saves most of the wasted time and efforts in hardware design and test, hence, a developer can focus his efforts on firmware development. All I/O pins are brought out via pin header for direct port accessing.
Eta32mini kit comes preprogrammed with UART bootloader, which eliminates the need for external programmer (programming using Eta32mini IDE from FARES PCB Co). However, kit can be programmed using Arduino IDE (another bootloader). Also standard 6 pin header socket is included (ICSP) for external programmers.
Eta32mini key features:
Power supply unit.
ATMEGA32 Microcontroller with reset switch and crystal oscillator.
4X4 matrix keypad.
Output unit involves three output LEDs, two output relays and one output buzzer.
Multiplexed two digits 7 segments display.
2X16 LCD display.
Variable analog input using high precise multi-turn resistor.
Virtual COM port via USB.
Standard 6 pin header socket ICSP for external programmers.
All microcontroller I/O pins are brought out via pin header.
Download User Manual (Click Here) & Software CD (Click Here)
SKU: KIT.AVR.MID-1
All Products, Digital Multimeter, UNI-T Brand Products
UT89X Digital Multimeter (NEW Featured Model)
| Specifications | Range | UT89X |
| DC voltage (V) | 600mV/6V/60V/600V/1000V | ±(0.5%+2) |
| AC voltage (V) | 6V/60V/600V/1000V | ±(0.8%+5) |
| DC current (A) | 60μA/60mA/600mA/20A | ±(0.8%+8) |
| AC current (A) | 60mA/600mA/20A | ±(1%+12) |
| Resistance (Ω) | 600Ω/6kΩ/60kΩ/600kΩ/6MΩ/60MΩ | ±(0.8%+3) |
| Capacitance (F) | 6nF/60nF/600nF/6μF/60μF/600μF/6mF/60mF/100mF | ±(2.5%+20) |
| Frequency (Hz) | 9.999Hz/9.999MHz | ±(0.1%+4) |
| Duty cycle | 0.1%~99.9% | ±(2%+5) |
| Temperature (℃) | -40℃~1000℃ | ±(2%+4) |
| Temperature (℉) | -40℉~1832℉ | ±(2%+8) |
| Features | ||
| Display count | 6000 | |
| Sampling rate | 3 times/s | |
| True RMS | √ | |
| AC voltage frequency response | 45~1000Hz | |
| AC current frequency response | 45~1000Hz | |
| Live wire test | √ | |
| Audible/visual alarm | V/A/Cap/Diode/hFE/NCV/Live (UT89X)/LED (UT89XD) | |
| Diode/Continuity test | √ | |
| Transistor hFE | √ | |
| Dual range NCV test | √ | |
| Auto power off | √ | |
| Low battery indication | √ | |
| Data hold | √ | |
| Function selection | SELECT | √ |
| Flashlight | √ | |
| Auto backlight | √ | |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 4 | |
| Display | 61mm x 36mm | |
| Product color | Red and grey | |
| Product net weight | 345g | |
| Product size | 189mm x 89mm x 53mm | |
| Standard accessories | Batteries, test lead, k-type temperature probe | |
SKU: AVO.UT89X.UNIT
All Products, Distance Meter, Environmental Meters & Testers, UNI-T Brand Products
LM40 Laser Distance Meter (up to 40 meter)
All Products, Distance Meter, Environmental Meters & Testers, UNI-T Brand Products
LM40 Laser Distance Meter (up to 40 meter)
| Specifications | LM40 |
| Display type | EBTN |
| Display size | 2.0-inches |
| Range | 40m |
| Min. display unit | 0.001m |
| Measurement units | m/ft/in |
| Measurement basis | front/rear |
| Accuracy | ±(2mm+5 x 10-5D) |
| Laser class | 2 |
| Laser type | 630~670nm, ﹤1mW |
| Features | |
| Single measurement | √ |
| Continuous measurement | √ |
| Max/Min/Area | √ |
| Volume | √ |
| Pythagoras | √ |
| Add/Subtract | √ |
| Data storage | 20 groups |
| Auto power off | 3 minutes without operation |
| Auto laser off | 30s without operation |
| Auto backlight off | 10s without operation |
| Audio indication | √ |
| Battery status display | √ |
| Storage temperature | -20℃~70℃ |
| Operating temperature | 0℃~40℃ |
SKU: AVO.LM40.UNIT
1/4W Kilo ohms Values, 1/4W Mega ohms Values, 1/4W Ohms Values, All Products, Capacitors, General Purpose BJT Transistors, LED's & LASER Sources
Electronic Components Starter Package
All Products, Clamp Meter | Power Meter, UNI-T Brand Products
Clamp Meter UT210E True RMS (NEW Model)
All Products, Clamp Meter | Power Meter, UNI-T Brand Products
Clamp Meter UT210E True RMS (NEW Model)
| Specifications | Range | UT210E |
| AC current (A) | 100A | ±(2.5%+5) |
| DC current (A) | 100A | ±(2%+3) |
| AC voltage (V) | 600V | ±(1%+3) |
| DC voltage (V) | 600V | ±(0.7%+3) |
| Resistance (Ω) | 20MΩ | ±(1%+2) |
| Capacitance (F) | 20mF | ±(4%+5) |
| Features | ||
| Display count | 2000 | |
| Continuity buzzer | √ | |
| Auto range | √ | |
| Jaw opening | 17mm | |
| Diode test | Around 3.0V | √ |
| General Characteristics | ||
| Power | 1.5V battery (R03) x 2 | |
| Display | 39.3mm x 26.5mm | |
| Product color | Red and grey | |
| Product net weight | 170g | |
| Product size | 175mm x 60mm x 33.5mm | |
| Standard accessories | Batteries, test leads | |
SKU: AVO.UT210E.UNIT
New Products
CNC & Motion Parts
All Products, Stepper Motors & Drivers
DM860H "2-phase Digital Stepper Drive; I/P:36-112Vdc or 24V—80Vac; O/P:2.4~7.2A
Soldering & Desoldering
All Products, PCB Sheets (Different Sizes), PCB Tools, Photo Resist PCB, Soldering & Desoldering
Flux Solution 125mL – ALPHA® ROSIN FLUX 800 (RF-800)
All Products, Microscope & Magnifiers, Other Tools, PCB Tools, Soldering & Desoldering
Magnifier With Alligators Holders & Solder Iron Stand
